LED Wash IP 65

LED Type: 10W RGBW 4in1 LEDs
LED Count: 44
LED Colors: RGBW

Movement

Resolution: 8-16 Bit
Position Feedback: yes
Tilt (Degrees): 185°

Control

Control Modes: 5CH / 12CH (CTC)
Display: Illuminated graphic LCD
Protocol: USITT DMX-512, RDM
RDM: Bidirectional communication
Wireless DMX: 2.4 GHz W-DMXTM (optional)
Cooling: Temperature controlled, overheating protection

Effects

Dimmer: 0-100% electronic
Shutter: electronic, max. 20 Hz
Color temperature filter: electronic, 2.000K - 10.000K
Internal Effects: LED Macro Effects
Angle: 25°, 35°, 45° (optional)

Connectors

Signal connection: Seetronic IP65 XLR 5-Pin or 3-Pin In/Out
Power Input: Seetronic powerCON TRUE1 In/Out

Operating Condtions

Mains voltage: 100-240V AC / 50-60Hz
Power: 450W
Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F
Operating Position: any

Mounting Options

Standing: Rubber feet
Hanging: Omega-Bracket
Safety wire attachment: foldout eyelets

Shipping

Single fixture: cardboard (inner and outer cartons)
Tourpack: 4-way Flight Case

Housing Colors

Standard colors: black

Dimensions

Length: 482 mm / 18.9 in
Width: 178 mm / 9.0 in
Height (head horizontal): 243 mm / 9.5 in

Weight N.W: 9.9 kg / N.W: 22 lbs
